Complete drawings of the aircraft.
STOL aircraft drawings SR701
STOL aircraft drawings SR701
This two-seater called the "Flying Jeep" razbeg- mileage of 20-25 meters.
Drawings aircraft STOL CH701,
look, buy, download and build.
To begin with basic technical harrakteristiki:
STOL CH 701 PERFORMANCE
ROTAX 912 (80 HP)
ROTAX 912S (100 HP)
SINGLE
DUAL
SINGLE
DUAL
TOP SPEED (MPH)
85
85
95
95
CRUISE, Sea Level (MPH)
80
80
85
85
75% CRUISE @ 8,000 ft. (TAS*)
92
92
98
98
VNE (MPH)
110
110
110
110
STALL (MPH)
28
30
28
30
RATE OF CLIMB (FPM)
1,100
1,000
1,200
1,100
TAKE-OFF ROLL (FEET)
60
115
50
90
LANDING ROLL (FEET)
80
140
80
140
SERVICE CEILING (FEET)
13,000+
12,000+
15,000+
12,000+
STD. RANGE (MILES)
372
372
350
350
ENDURANCE
4.6 Hrs.
4.6 Hrs.
4.1 Hrs.
4.1 Hrs.
SPECIFICATIONS
STOL CH 701
WING SPAN
27 FEET
8.2 m.
WING AREA
122 SQ.FT.
11.4 m.sq.
LENGTH
20 Ft. 11 In.
6.38 m.
HEIGHT (rudder tip)
8 Ft. 7 In.
2.6 m.
EMPTY WEIGHT
580 LBS.
263 kg.
GROSS WEIGHT
1,100 LBS.
500 kg.
USEFUL LOAD
520 LBS.
236 kg.
WING LOADING
9.0 LBS/FT?
43.8 m?
POWER LOADING
13.75 LBS/BHP
6.25 kg/BHP
DESIGN LOAD FACTOR (ultimate)
+6 G / -3G
CABIN WIDTH (shoulders)
40 INCHES
100 cm.
CABIN WIDTH (optional bubble doors)
44 INCHES
110 cm.
FUEL CAPACITY (std., dual wing tanks)
20 US Gallons
(2 x 10 gal.)
76 liters
(2 x 38 liters)
Drawings in pdf, you can easily print on your home printer and build your plane.
