SolarEdge P340-5NM4MRS Power Optimizer SolarEdge, Optimizer 340W/ 48Vdc Input for 60-cell high-power modules, MC4 connectors, P320-5NC4ARS *The SE-P340-5NM4MRS units are functionally equivalent to the SE-P340, and can be mixed in the same orders / strings All SolarEdge power optimizers can be used with crystalline silicon PV modules to provide module-level MPPT and performance monitoring, and are designed to work exclusively with SolarEdge inverters. All power optimizers have 99.5% peak efficiency and are backward compatible with older SolarEdge products. The P320, P370, and P400 optimizers can be used with any SolarEdge inverter, while the P600, P700 and P730 dual-module optimizers are compatible only with SolarEdge three-phase inverters. The P320 is specifically designed for use with 60-cell modules that have nameplate ratings of between 300 and 320 W DC. SolarEdge optimizers can be attached to most PV mounting systems using a single fastener; grounding can be accomplished via the included star washer, a WEEB, or through a lug, depending on racking. AEE Solar maintains stock of optimizers with MC4 input and MC4 output connectors. Optimizers with H4 connectors are available upon request. Features Efficiency - Up to 25% more energy. Superior efficiency (99.5%). Mitigates all types of module mismatch losses, from manufacturing tolerance to partial shading. Flexible system design for maximum space utilization. Fast installation with a single bolt. Next generation maintenance with module-level monitoring. Module-level voltage shutdown for installer and firefighter safety. Mechanical Data Technology: Optimizer Dimensions: 5.00 x 5.97 x 1.89 Inches Weight: 1.70 lbs Maximum Allowed System Voltage: 1000 VDC Compatible Inverters: All SolarEdge Single Phase and Three Phase Inverters Input Connector: MC4 Compatible Output Wire Type/Connector: Double Insulated; MC4 Compatible Output Wire Length: 3.00 Feet Operating Temperature Range: -40 to +85C Protection Rating: IP68/NEMA6P Relative Humidity: 0-100% EMC Compliance: FCC Part15 Class B, IEC61000-6-2, IEC61000-6-3 Safety: IEC62109-1 (Class II Safety), UL1741 RoHS Compliance: Yes Electrical Data Rated Input DC Power: 340 Watts Absolute Maximum Input Voltage: 48 VDC MPPT Operating Range: 8-48 Volts Maximum Short Circuit Current (Isc): 11 ADC Maximum DC Input Current: 13.75ADC Maximum Efficiency: 99.50% Weighted Efficiency: 98.80% Maximum Output Current: 15 ADC Maximum Output Voltage: 60 VDC Safety Output Voltage per Power Optimizer: 1 VDC Thanks for looking at our listing and supporting our small family business! Take a look at our other new and used solar equipment! We can combine shipping! SHELF: 55
