PRINTER SPECIFICATIONS:
Printing Method: Direct Thermal Printing
Printing Speed: Max. 100mm/s, 3.94"in/s
Resolution: 8 dots/mm, 384 dots/line
Effective Printing Width: 48mm, 1.89"in
Character Character Set: GB2312, 16x16dots, or 24x24dots
Character: 8x16dots, or 12x24dots?9x17dots
Character per Line: 32
Paper Spec Paper Type: Thermal paper
Paper Width: 57.5 0.5mm, 2.26 0.02"in
Paper Roll Diameter: Max. 83.0mm, 3.27"in
Roll Core Inner Diameter: 13mm(min.), 0.51"in(min.)
Paper Thickness: 0.06 to 0.07mm, 0.0024" to 0.0027"in
Paper out detection: Support
Paper Supply Method: Drop-in Paper Load
Reliability MCBF: 5 million lines
Printer Head Life: 100km Printing length
Bar code type: UPC-A,UPC-E, EAN-13,EAN-8,CODE39,
ITF,CODEBAR,CODE93,CODE128,QRCODE
PRINTER FEATURES:
• Long life, high speed, durable performance
• Low noise direct thermal printing
• Exquisite design and easy to use
• Function setup, auto-printing prompt
• Emulation: ESC/POS
• Driver: WIN2003/WINXP/WIN7/WIN8/WIN10
• Drawer Port: 1 Port
• Interface: U?US?S?P
• Input Power: 12V,2A
• Cash box control: 12V, 24V
• Net Weight: 400g
• Gross Weight: 1.0kg
• Printer Dimension (WxLxH): 210mm(L)x135mm(W)x126mm(H) 8.27"in(L)x 5.31"in(W)x 4.96"in(H)
• Application: Restaurants, Department Stores, Kitchen, Convenience Stores, Specialty Retail, Super market.
Additional Details
------------------------------
Bullet point: ??????? ???????: Printing method is direct thermal printing. Printing speed is max 100mm/s, 3.94"in/s, Resolution: 8 dots/mm, 384 dots/line Effective Printing Width 48mm, 1.89"inch. Thermal printer is designed to work with the Indicator series in which you can use thermal roll paper. The width of thermal paper is 57.5 0.5mm, 2.26 0.02"in Paper thickness 0.06 to 0.07mm, 0.0024" to 0.0027"in. Printer head life is 100km printing length.
Product description:
PRINTER SPECIFICATIONS:
Printing Method: Direct Thermal Printing
Printing Speed: Max. 100mm/s, 3.94"in/s
Resolution: 8 dots/mm, 384 dots/line
Effective Printing Width: 48mm, 1.89"in
Character Character Set: GB2312, 16x16dots, or 24x24dots
Character: 8x16dots, or 12x24dots?9x17dots
Character per Line: 32
Paper Spec Paper Type: Thermal paper
Paper Width: 57.5 0.5mm, 2.26 0.02"in
Paper Roll Diameter: Max. 83.0mm, 3.27"in
Roll Core Inner Diameter: 13mm(min.), 0.51"in(min.)
Paper Thickness: 0.06 to 0.07mm, 0.0024" to 0.0027"in
Paper out detection: Support
Paper Supply Method: Drop-in Paper Load
Reliability MCBF: 5 million lines
Printer Head Life: 100km Printing length
Bar code type: UPC-A,UPC-E, EAN-13,EAN-8,CODE39,
ITF,CODEBAR,CODE93,CODE128,QRCODE
PRINTER FEATURES:
• Long life, high speed, durable performance
• Low noise direct thermal printing
• Exquisite design and easy to use
• Function setup, auto-printing prompt
• Emulation: ESC/POS
• Driver: WIN2003/WINXP/WIN7/WIN8/WIN10
• Drawer Port: 1 Port
• Interface: U?US?S?P
• Input Power: 12V,2A
• Cash box control: 12V, 24V
• Net Weight: 400g
• Gross Weight: 1.0kg
• Printer Dimension (WxLxH): 210mm(L)x135mm(W)x126mm(H) 8.27"in(L)x 5.31"in(W)x 4.96"in(H)
• Application: Restaurants, Department Stores, Kitchen, Convenience Stores, Specialty Retail, Super market.
