Features: 5MP, 2560 1944 resolution, 24-hour color image, 2.8 mm fixed lens, Up to 66ft(20 m) white light distance, 3D DNR, true WDR, 4 in 1 video output (switchable TVI/AHD/CVI/CVBS), IP67, OSD menu via UTC technology with Platinum DVR 5MP, 2560 1944 resolution 24-hour color image 2.8 mm fixed lens 0.0005Lux@F1.0 Up to 66ft(20 m) white light distance 3D DNR, true WDR 4 in 1 video output (switchable TVI/AHD/CVI/CVBS) IP67 OSD menu via UTC technology with Platinum DVR Camera Image Sensor 5 MP CMOS Resolution 2560 (H) 1944 (V) Frame Rate 5MP@20fps Min. illumination 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light Shutter Time PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s Slow Shutter Max. 16 times Lens 2.8 mm fixed lens Field of View 2.8 mm, horizontal FOV: 104, vertical FOV: 54, diagonal FOV: 126 Lens Mount M16 Day Night Color WDR (Wide Dynamic Range) 120 dB Angle Adjustment Pan: 0 to 360; Tilt: 0 to 75; Rotate: 0 to 360 Menu Image Mode STD/HIGH SAT AGC Yes White Balance Auto/Manual HLC Yes BLC (Backlight Compensation) Yes Privacy Mask 4 programmable privacy masks Motion Detection 4 programmable areas WDR Yes Functions Brightness, Sharpness, 3D DNR, Mirror, Smart light Interface Video Output Switchable TVI/AHD/CVI/CVBS General Operating Conditions -40 C to 60 C (-40 F to 140 F), humidity: 90% or less (non-condensing) Power Supply 12 VDC 25% *You are recommended to use one power adapter to supply the power for one camera. Power Consumption Max. 3 W Protection Level IP67 Material Main Body: Metal Mounting Base: Plastic White Light Up to 66ft(20 m) Dimensions O 109.82 mm 85.56 mm ( O 4.32" 3.37") Weight Approx. 336 g (0.74 lb.) We accept payment by Paypal, all major Credit card, Debit Card. Please make sure to leave item number with payment. If any special requirement needs, please leave a note while check out. Payments are expected within 7 days after the last winning auction is closed. Unpaid item (UPI) complaint will be filed with upon non-receipt of payment. Bidding on multiple auctions? Simply wait until all of the auctions have ended, and complete the checkout from the most recent email that you received from us. Once you have completed the checkout, you will not be able to combine any additional auctions. We start to process and rush your order once checkout is completed with payment. We are required to collect 8.25% Texas sales tax when Ship-To address is in Texas. We ship worldwide from United State. Most order ship in same day by 4pm central time on business day only. Please make sure the Ship-To address you input during checkout is correct. We are NOT responsible for any wrong or undeliverable addresses. Tracking number will be send to your email once the item shipped. Shipping and handling rates shown on Shipping and Payments detail section apply to 50 US States, Puerto Rico, APO and FPO addresses and other US territories with a valid US zip code. note: APO/FPO or any military address are not eligible for delivery confirmation due to postal restriction. We also charge flat rate S H for International shipment; however it may vary from country to country. Please select your country in the Shipping and Payments detail section for the rate to your country. Business Hour 9:00Am to 5:30Pm (Monday to Friday) Central Time. We try our best to answer your questions less than 4 Business Hours. Otherwise we will response your email within 1 day. We are aware that the communication problems between the seller and the buyer could be frustrating if left unresolved. We would like to let you know that we will respond to all after-sale questions based upon our knowledge. If you asked a question and did not get any response in 1day, please try again, and if you still did not get any response in the next 2 days, it could be either that we do not receive your emails or you do not get our email answers. In this case, please check your email server, email address quotas and/or spam email folder and try again, and if you still do not get any response, please call us at contact number in contact us page during the business hour. Please be ready your ID and item number before you call. Please keep all material including shipping label for return. All item has been tested before we ship out. So you will not receive defective item. Money Back Guarantee and Replacement Warranty terms start from the date you receive the item. Physically damaged items cannot be returned. If you receive a DOA (Dead on Arrival) item, please contact us within 14 days. Returns/Exchanges will not be accepted unless authorization has been issued Customer Service Department. To receive an RMA (Returns Merchandise Authorization) number please send an email to with a copy or the original invoice and return form. For more information about return policy. Please review our Return Policy page location on the bottom of the page. Chili Inc. All rights reveserved. Chili, the Chili logo are trademarks or registered trademarks of Chili Inc.
